PC-A: Band Saw Machine

Twin Head Horizontal Band Resaw

PC-A911 Horizontal Resaw Machine

PC-A911 Horizontal Resaw Machine

PC-A911 Horizontal Resaw Machine
PC-A911
Product Description
proimages/pro/Woodworking_Machine/A911a.jpg

Hydraulic motor for conveyor drive

The feeding speed can be adjusted for different wood hardness.


proimages/pro/Woodworking_Machine/A911b.jpg

Saw wheel elevation motor

The upper and bottom saw wheel elevation have individual motors to drive, it’s convenient to adjust the cutting thickness


proimages/pro/Woodworking_Machine/A911c.jpg

Height and position of steel pressure roller could be easily adjusted.

Inquiry
FEATURES:
  • Our horizontal resaw machine has two saw head configuration.
  • Motor powered set works for accurate saw wheel elevation.
  • Digital position controllers permit accurate saw wheels height positioning.
  • Automatic blade tension is controlled by hydraulic cylinder.
  • Variable feed speed by hydraulic motor drive.
MODELPC-A911
Max Workpiece size (W x H) 300 x 250 mm (12"x10")
Distance from upper blade to conveyor table 20~170 mm (3/4" x 6-3/4")
Distance from lower blade to conveyor table 12 to125 mm (Optional 5 to125mm)
Distance between two blades 12 mm
Conveyor belt size 285x5480 mm (11-1/5"x215-3/4")
Saw wheel diameter Ø 28" x 1"(W)
Feed speed 5 to 25 M/min
Saw blade size (L x W x T) 4265 x 27 x 0.90 mm (168" x 1")
Saw wheel motor 20 HP x 2
Hydraulic system motor 3HP
Gear box motor 1/4 HP x 2
Dust hood diameter Ø 4" x 2
Net weight 1400 Kg
Packing dimensions 2180 x 1140 x 2100 mm
Conveyor / Frame 2870 x 640 x 600 mm
